Newmar Bay Star Motor Home Class A

Previous
Next
1 of 17

The Bay Star gas Class A from Newmar puts quality construction within reach. These motorhomes simply refuses to look--or feel--like anything less than a luxury RV. Throughout the models you will find stylish cabinet colors, a comfortable master suite, plus a cockpit audio system this is sure to please everyone!



Bay Star gives you a variety of different floorplans which all feature Newmar's inventive flat-floor slideouts and a generous list of features to choose from. You will enjoy the spacious bathrooms, and select models feature two sinks vanities! Newmar believes that living life on the road shouldn't mean forgoing comfort for a reasonable price. So let Newmar get you started in the RV world of adventure with a brand new Bay Star gas Class A motorhome today!
  • Bay Star 3009

    Bay Star 3009 Floorplan Image

    Triple slide outs, a walk-through bathroom, and sleeping space for your family ... more about Bay Star 3009

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 6
    Slides 3
    Length 30 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 17494 lbs
    Cargo Weight 4506 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 200 in
    Available Beds Queen
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 38" x 26" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR LED TV, BR TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3113

    Bay Star 3113 Floorplan Image

    Easily set out on your next road adventure, whether you want to travel across ... more about Bay Star 3113

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 3
    Length 31 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 17834 lbs
    Cargo Weight 4166 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 200 in
    Available Beds King
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 36" x 36" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR LED TV, BR LED TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Radius
    Electrical Service 30 amp
  • Bay Star 3124

    Bay Star 3124 Floorplan Image

    This Bay Star 3124 motor home by Newmar offers plenty of room with a full wall ... more about Bay Star 3124

    Specifications

    Sleeps 5
    Slides 2
    Length 31 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 18174 lbs
    Cargo Weight 3826 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Available Beds King
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 36" x 36" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info BR TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Radius
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3208

    Bay Star 3208 Floorplan Image

    Easily entertain a guest or two in this 3208 Bay Star by Newmar. This class A ... more about Bay Star 3208

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 2
    Length 32 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Angora, Intrigue
    Exterior Color Angora, Intrigue
    Gross Weight 22000 lbs
    Dry Weight 18514 lbs
    Cargo Weight 3486 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 KW Cummins Onan
    Fuel Type Gas
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 200 in
    Available Beds Queen
    Refrigerator Type Black Panel Front
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 36" x 30" in
    Number of Awnings 3
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    AC BTU 13500 btu
    TV Info Living Area TV
    Awning Info Side Awning, (2) Slide Out Topper Awnings
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3306

    Bay Star 3306 Floorplan Image

    Let this 3306 Bay Star motor home class A take your family of six on a trip of a ... more about Bay Star 3306

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 6
    Slides 3
    Length 33 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Angora, Intrigue
    Exterior Color Angora, Intrigue
    Gross Weight 22000 lbs
    Dry Weight 18854 lbs
    Cargo Weight 3146 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 KW Cummins Onan
    Fuel Type Gas
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 216 in
    Number Of Bunks 1
    Available Beds Queen
    Refrigerator Type Black Panel Front
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 38" x 26" in
    Number of Awnings 4
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    AC BTU 13500 btu
    TV Info Living Area
    Awning Info Side Awning, (3) Slide Out Topper Awnings
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3333

    Bay Star 3333 Floorplan Image

    Enjoy your time away from home in this triple slide out class A motor home by ... more about Bay Star 3333

    Specifications

    Sleeps 4
    Slides 3
    Length 33 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 19114 lbs
    Cargo Weight 2886 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 216 in
    Available Beds Queen
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 36" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR TV, BR TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Radius
    Electrical Service 30 amp
  • Bay Star 3401

    Bay Star 3401 Floorplan Image

    Let this Bay Star 3401 motor home by Newmar take you on your next trip in style! ... more about Bay Star 3401

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 2
    Length 34 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 19186 lbs
    Cargo Weight 2814 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 220 in
    Available Beds King
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 36" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR TV, BR TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Radius
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3403

    Bay Star 3403 Floorplan Image

    You can easily entertain guests or friends inside this 3403 Bay Star motor home ... more about Bay Star 3403

    Specifications

    Sleeps 6
    Slides 3
    Length 34 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 19178 lbs
    Cargo Weight 2822 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 92 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 216 in
    Available Beds Queen
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 40" x 26" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR TV, BR TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3406

    Bay Star 3406 Floorplan Image

    Let this 3406 Bay Star motor home class A take your family of six on a trip of a ... more about Bay Star 3406

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 6
    Slides 3
    Length 34 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 18540 lbs
    Cargo Weight 3460 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 86 gals
    Black Water Capacity 60 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 220 in
    Number Of Bunks 1
    Available Beds Queen
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 40" x 26" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3414

    Bay Star 3414 Floorplan Image

    Let this 3414 Bay Star class A motor home be your home on wheels. With triple ... more about Bay Star 3414

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 3
    Length 34 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 22000 lbs
    Dry Weight 19178 lbs
    Cargo Weight 2822 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 86 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 220 in
    Available Beds Queen
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 40" x 26" in
    Number of Awnings 1
    Axle Weight Front 8000 lbs
    Axle Weight Rear 15000 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR LED TV, BR TV
    Awning Info Power
    Gross Combined Weight 26000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3516

    Bay Star 3516 Floorplan Image

    Triple slide outs, plenty of room to entertain a guest or two, and a rear ... more about Bay Star 3516

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 3
    Length 35 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Angora, Intrigue
    Exterior Color Angora, Intrigue
    Gross Weight 24000 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 KW Cummins Onan
    Fuel Type Gas
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 228 in
    Available Beds King
    Refrigerator Type Black Panel Front
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 36" in
    Number of Awnings 3
    Axle Weight Front 9000 lbs
    Axle Weight Rear 15500 lbs
    LP Tank Capacity 25 lbs.
    AC BTU 13500 btu
    TV Info Living Area TV, Bedroom TV
    Awning Info Side Awning, Slide Out Topper Awnings
    Gross Combined Weight 30000 lbs
    Shower Type Radius
    Electrical Service 30 amp
  • Bay Star 3518

    Bay Star 3518 Floorplan Image

    You can easily entertain friends with this 3518 Bay Star motor home by Newmar. ... more about Bay Star 3518

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 3
    Length 35 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 24000 lbs
    Dry Weight 19322 lbs
    Cargo Weight 4668 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 228 in
    Available Beds King
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 40" x 26" in
    Number of Awnings 1
    Axle Weight Front 9000 lbs
    Axle Weight Rear 15500 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR LED TV, BR TV
    Awning Info Power
    Gross Combined Weight 30000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Bay Star 3532

    Bay Star 3532 Floorplan Image

    You will want your next road trip to extend just a little bit longer with this ... more about Bay Star 3532

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 6
    Slides 3
    Length 35 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 12 ft 8 in
    Int Height 6 ft 8 in
    Interior Color Intrigue, Whitecap
    Exterior Color Intrigue, Whitecap
    Hitch Weight 5000 lbs
    Gross Weight 24000 lbs
    Dry Weight 19322 lbs
    Cargo Weight 4668 lbs
    Fresh Water Capacity 75 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Furnace BTU 40000 btu
    Generator 4.0 kW Cummins Onan
    Fuel Type Gas
    Engine Triton V10
    Chassis Ford F-53
    Horsepower 320 hp
    Fuel Capacity 80 gals
    Wheelbase 228 in
    Available Beds Queen
    Torque 457 ft-lb
    Refrigerator Size 8 cu ft
    Convection Cooking Yes
    Cooktop Burners 3
    Shower Size 40" x 26" in
    Number of Awnings 1
    Axle Weight Front 9000 lbs
    Axle Weight Rear 15500 lbs
    LP Tank Capacity 25 lbs.
    Water Heater Capacity 6 gal.
    AC BTU 13500 btu
    TV Info LR LED TV, BR TV
    Awning Info Power
    Gross Combined Weight 30000 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

Bay Star Features:

Standard Features (2018)



Exterior
  • Exterior Masterpiece™ Full Painted Graphics with Clearcoat Finish
  • Dura Shield Protection on Front Cap
  • Lighted Exterior Storage Compartments
  • Automatic Step for Entrance Door
  • Convex Exterior Mirrors with Defrost
  • Rear Hitch for Towing Car
  • Assist Handle at Entrance Door
  • Undercoating
  • Mud Flaps
  • Hydraulic Leveling Jacks

Options

  • Convex Exterior Mirrors with Defrost and Remote Control
  • Rear Ladder
  • Flag Pole Bracket
  • Exterior Kitchen
  • Temporary Windshield Protection for Transport
Construction
  • BriteTEK Roof with Walkable Deck
  • Gelcoated Fiberglass Exterior Sidewalls, Front & Rear Caps
  • Aluminum-Frame Sidewalls & Roof Construction, on 16" Center
  • 5/8" Foam Insulation Laminated in Sidewalls & Ceiling

Options

  • Polar Pak R19 batten Insulation in Roof
Windows, Awnings & Vents
  • One Piece Tinted Windshield
  • Frameless Single Pane Tinted Safety-Glass Windows
  • Power Vent in Kitchen and Bathroom
  • Skylight Above Shower
  • Dometic® Weather Pro Side Awning with Aluminum Weather Shield
  • Slideout Covers

Options

  • Frameless Double-Pane Tinted Safety Glass Windows
  • Rear Window in Bedroom
  • Fantastic Vent with Rain Sensor in Kitchen & Bathroom

Air Conditioning & Heating

  • 13.5M Brisk® Central Air Conditioner
  • Dash Heater and Air Conditioner
  • Defrost Fans Built into Front Overhead
  • Driver & Passenger Overhead Dash Fans
  • Propane Gas Furnace with Ducted Heat

Options

  • 15.0M Penguin, Heat Pump Air Conditioner*
  • Two 13.5 Penguin Heat Pump A/C, 5.5 Onan Generator, 50 Amp Electrical Service with Energy Management System
  • Auxillary Heater in Bedroom

Electrical

  • 4.0 kW Cummins Onan® Generator with Remote Switch and Automatic Changeover
  • 30 Amp Electrical Service with Flexible Cord and Automatic Transfer Switch
  • Two 12 Volt House Batteries
  • Battery Disconnect Switch for House Battery
  • 12 Volt Auxiliary Receptacle on Dashboard
  • 45 Amp Converter
  • Daytime Running Lights
  • Emergency Engine Start Switch
  • LED Ceiling Lights
  • Manually Operated Hold-To-Run Slideout Switch
  • Cable TV Connection
  • 10 Watt Solar Panel to Charge Chassis Battery
  • 1000 Watt Inverter Run to Drain Lift Pump & TV™s on 3403 & 3712 Floorplans
  • Lights in Wardrobes
  • USB Chargers at Driver/Passenger Seat Area

Options

  • 1000 Watt Inverter Ran to TV™s
  • 50 Amp Electrical Service
  • Solar Prep Rated for 1200 Watts with Six Gauge Wire from Roof to House Battery Compartment

Plumbing & Bath

  • Demand Water System
  • Sewage Holding Tank Rinse
  • Water Heater Bypass System
  • Dometic® 310 China Bowl Stool
  • ABS Shower Surround with Shower Door
  • Systems Monitor Panel
  • Exterior Shower

Options

  • Water Filter for Entire Unit

Cabinets & Furniture

  • Calypso Glazed Maple Mitered Designer Cabinet Doors-Opt. Matte Finish
  • Drawers with Full-Extension Guides
  • Polished Solid Surface Countertop in Kitchen with Stainless Steel Sink
  • Solid Surface Countertops in Bathroom and Bedroom
  • Flexsteel® Ultralux Leather Sofa and Front Seats
  • Lifts on Bed Top
  • Smooth-Top Mattress
  • Passenger Seat Work Station
  • Manual Foot Rest on Passenger Seat
  • Pullout Pantry Shelves

Options

  • Astoria Glazed Maple Mitered Designer Cabinets-Opt. Matte Finish
  • Sienna Glazed Maple Mitered Designer Cabinets-Opt. Matte Finish
  • Combination Desk with Buffet Dinette Table, 2 Fixed & 2 Folding Chairs
  • Combination Desk/Dinette with Free Standing Hidden Leaf Table, 2 Fixed & 2 Folding Chairs
  • Buffet Dinette with Free Standing Table
  • Buffet Dinette
  • Free Standing Hidden Leaf Dinette Table, 2 Fixed & 2 Folding Chairs
  • Drop Down Bunk Bed Over Driver/Passenger Seats with Electric Release Latches
  • Drop Down Bunk Bed Over Driver/Passenger Seats with Electric Release Latches and 32" TV in Front Overhead
  • Plush Pillow Top Mattress
  • Folding Cockpit Table
  • Hide A Bed Sofa
  • Off Door Side-Side Opening Hide-A-Bed Sofa
  • Off Door Side 74 Fold & Tumble Sofa with Air Mattress
  • Side Opening Hide-A-Bed Sofa
  • Six Way Power for Driver Seat
  • 84" Hide-A-Bed Sofa
  • 87" Bunk Sofa

Appliances

  • Three-Burner Range with Oven
  • 30" Over the Range Microwave
  • Norcold® 8 Cf. Refrigerator
  • Raised Panel Refer Door Insert Panel
  • 6 gal. Gas/Electric Water Heater with Electronic Ignition

Options

  • Frigidaire 10 Cf. Regrigerator with Dedicated 1000 Watt Pure Sine Inverter & 2 Extra Batteries
  • Norcold 12 Cf. 4-Door Regrigerator with Icemaker
  • Icemaker Added to Standard Norcold Refrigerator with Heated Water Line
  • 30" Convection Microwave with 3 Burner Cooktop
  • Fireplace in Living Area (Requires 50amp Service Option)
  • 110 Volt Heat Pads for Holding Tanks

Interior

  • Vinyl Ceiling Panels
  • Decorative Wall Art
  • Mini Blinds in Kitchen and Bathroom Windows
  • Vinyl Floor in Kitchen, Living Area and Bathroom
  • Carpeting in Bedroom and on Slideout floors
  • Interior Assist Handle at Main Entrance Door
  • Quilted Bedspread, Bed Scarf & Accent Pillow
  • Inlayed Six Panel Design Interior Passenger Doors
  • Auto Motion Manual Double Roller Shades on Windows Behind Driver/Passenger Area
  • Auto Motion Power Shade at Windshield & Manual Shades at Driver & Passenger Side Windows
  • Dash Panel Color Coordinated ABS
  • 10 Bc Fire Extinguisher, Smoke Detector, Propane and Carbon Monoxide Detector
  • Shoe Storage Located in Entrance Door Step Compartment

Options

  • Vinyl Tile Floor in Place of Vinyl Floor

Audio, Video & Accessories

  • Sony LED TV & DVD Player in Living and Bedroom Areas (TV sizes vary per floorplan)
  • Dash Radio/CD Player with Harman/JBL 180 Watt Sound System
  • Rearview Colored Monitor System with Audio
  • Winegard Digital TV Antenna
  • Satellite Dish Prep on Roof
  • High Definition Component Wiring
  • TV Jack and 110 Volt Recept in Door Side Exterior Storage Compartment
  • Bluetooth Microphone for Sony Dash Radio

Options

  • 32" LED TV in Front Overhead
  • 32" LED TV in Exterior Storage Compartment
  • 32" LED TV Exterior TV Only
  • Blu-Ray Disc Players
  • Side View Cameras Displayed onto Rear View Monitor Screen
  • Sirius Radio Capability with Antenna (Does Not Include Monthly Subscription)
  • Bose Solo 5 Sound Bar Sound System
  • Wifi Ranger Skypro Pack Router
  • Xite Dash Radio, 6 Monitor with Rand McNally Navigation
  • Winegard Automactic Open Face Satellite Dish
  • Winegard® Automatic Dome Satellite Dish
  • Winegard in Motion Dome Satellite Dish
  • Winegard Automatic Open Face Swm Satellite
  • Winegard Cellular In Motion Wifi



See us for a complete list of features & available options!



All standard features and specifications are subject to change.

Manu-Facts:

In 1968, Marvin Miller and Marvin Newcomer left their jobs at an RV manufacturer and founded the Newmar Corporation in Nappanee, Indiana. Their goal? Build coaches that were better than anything else on the road.

Newmar began by building high-quality travel trailers. In 1971, the company introduced the Kountry Aire fifth wheel, making Newmar one of the first and largest fifth wheel builders in the industry.

Newmar continued to grow at a rapid pace through the 1970s. In 1984, Mahlon Miller, who at the time was president of the Holiday Rambler Corporation, left his position and purchased a 51% stake in the Newmar Corporation.

In the 1980s, Newmar entered the Class A market, building premium-quality motor coaches in small numbers. In 1990, the company introduced two iconic motor coaches that still exist today: Dutch Star and Mountain Aire. At the same time, Newmar began pioneering concepts and features that would change the industry, including the first traditional slideouts and flush floor slideouts ever featured in a Class A coach.

In 1991, Mahlon Miller purchased the remaining 49% of Newmar Corporation, becoming sole owner. Just one year later, the company built a new, 116,000 square foot, state-of-the-art manufacturing facility in Nappanee, helping to further centralize production.

By the late 1990s, Newmar became the first to offer full body paint on both its towable and motor coach products. To support the growth of this innovative practice and ensure superior quality, Newmar added a 45,000 square foot paint facility. Then, in 2004, a 150,000 square foot chassis prep and welding facility was added to accommodate the growing complexities that come with manufacturing top-quality motor coaches.

In 2006, Mahlon Miller’s son Matt became Newmar’s new president. When the economic recession arrived soon thereafter, Matt Miller insisted Newmar stay the course by maintaining its commitments to dealers and customers. In 2012, Newmar exited the fifth wheel segment that helped shape the company decades earlier, choosing to focus entirely on crafting the finest Class A motorhomes the industry had ever seen.

Today, Newmar is stronger than ever thanks to an unwavering commitment to service, quality and innovation that remains unmatched.
